Heap Sort Algorithm

In this article, we will discuss the Heapsort Algorithm. Heap sort processes

the elements by creating the min-heap or max-heap using the elements of

the given array. Min-heap or max-heap represents the ordering of array in

which the root element represents the minimum or maximum element of

the array.

Heap sort basically recursively performs two main operations -

oBuild a heap H, using the elements of array.

oRepeatedly delete the root element of the heap formed in 1st phase.

Before knowing more about the heap sort, let's first see a brief description

of Heap.

What is a heap?

A heap is a complete binary tree, and the binary tree is a tree in which the

node can have the utmost two children. A complete binary tree is a binary

tree in which all the levels except the last level, i.e., leaf node, should be

completely filled, and all the nodes should be left-justified.

33.4M

726

Exception Handling in Java - Javatpoint

What is heap sort?

Heapsort is a popular and efficient sorting algorithm. The concept of heap

sort is to eliminate the elements one by one from the heap part of the list,

and then insert them into the sorted part of the list.

Heapsort is the in-place sorting algorithm.

Now, let's see the algorithm of heap sort.

Algorithm

1. HeapSort(arr)

2. BuildMaxHeap(arr)

3. for i = length(arr) to 2

4. swap arr[1] with arr[i]

5. heap_size[arr] = heap_size[arr] ? 1

6. MaxHeapify(arr,1)
