Following table gives the comparison between the two types of condensers.

Jet Condensers

Surface Condensers

  1. Contact between steam and cooling water is direct. They form a mixture of condensate and water after heat exchange.

  2. Condensate is not fit for reuse as boiler feed water since circulating water contains impurities.

  3. Vacuum rarely exceeds 650 mm of mercury.

  4. Quantity of cooling water is less.

  5. Less maintenance cost.

  6. Low manufacturing cost.

  7. Requires less floor area.

  8. More auxiliary power required.

  9. Exhaust steam and cooling water do not come into contact directly. Condensate and circulating water never mix together.

  10. Condensate is quite fit for reuse as boiler feed water.

  11. Very high vacuum can be created. So higher plant efficiency.

  12. Larger quantity of water is required.

  13. Maintenance cost is high.

  14. High manufacturing cost.

  15. Requires large floor area.

  16. Less auxiliary power required.
