Owner’s Manual (this document) Read this rst. It explains the basic things you need to know in order to use the RD-88. PDF Manual (download from the Web) 5 Parameter Guide This explains all parameters of the RD-88. 5 Sound List This is a list of the sounds built into the RD-88. 5 MIDI Implementation This is detailed information about MIDI messages. To obtain the PDF manual
- Enter the following URL in your computer. roland/manuals/ I
- Choose “RD-88” as the product name. Before using this unit, carefully read “USING THE UNIT SAFELY” and “IMPORTANT NOTES” (the lea et “USING THE UNIT SAFELY” and the Owner’s Manual (p. 28)). After reading, keep the document(s) where it will be available for immediate reference. © 2020 Roland Corporation Owner’s Manual
Contents
- Introduction
- Placing the RD-88 on a Stand.
- Turning the Power On and Off
- Panel Descriptions
- Top Panel.
- List of Shortcut Keys
- Rear Panel (Connecting Your Equipment)
- Overview of the RD-88
- Basic Organization of the RD-88
- About Scenes.
- Basic Operation.
- Main Screens
- About the Cursor Buttons
- Editing a Value.
- Performance
- Listening to the Demo (DEMO PLAY)
- Piano Performances
- Performing with a Variety of Scenes
- Playing Multiple Tones with the Keyboard
- Performing with Layered Tones (Dual Mode)
- Keyboard (Split Mode) Playing Different Tones in Two Different Sections of the
- Changing the Tone for a ZONE
- Adjusting the Volume Level for Individual Zones
- Changing the Key Touch
- Transposing the Key of the Keyboard (TRANSPOSE)
- Adding Reverberation to the Sound (REVERB)
- Adding Breadth to the Sound (CHORUS/DELAY)
- Modifying the Sound in Real Time (WHEEL1/2)
- Adding Liveliness to the Sound (COMPRESSOR)
- Adjusting the Character of the Sound (TONE COLOR).
- Applying Various Effects to the Sound (MFX)
- Adjusting the Levels of Each Frequency Range (EQUALIZER)
- Disabling the Buttons (Panel Lock)
- Using the Convenient Functions in Performances
- (FAVORITE) Registering Frequently-Used Sounds (Scenes) to Buttons
- Registering a Favorite
- Recalling a Favorite
- Switching the Favorite Bank
- Viewing the Favorite List
- Deleting a Favorite
- Playing Rhythm.
- Changing Rhythm Tempos
- Changing the Rhythm Pattern
- Playing Songs
- Assigning the Function of Each Controller
- Using the [ONE TOUCH PIANO] Button
- Using the RD-88 as a Master Keyboard.
- What’s MIDI?
- Settings for Controlling an External Sound Module
- Connecting a Computer (USB COMPUTER Port)
- Installing the USB Driver.
- USB Driver Settings
- Making Detailed Settings for Tones
- Editing a Scene
- Saving a Scene (Write)
- Editing the System Effects.
- Saving the System Effects (Write)
- Other Functions
- Convenient Functions (UTILITY)
- Backing Up Data to USB Flash Drive (BACKUP)
- Restoring Backup Data (RESTORE)
- Adding the Sounds (IMPORT TONE)
- Returning to the Factory Settings (FACTORY RESET)
- Formatting a USB Flash Drive (FORMAT USB MEMORY)
- Editing the System Settings (SYSTEM)
- Saving the System Settings (System Write)
- Viewing the Program Version (INFORMATION)
- USING THE UNIT SAFELY
- IMPORTANT NOTES
- Main Speci cations
Panel Descriptions
1 WHEEL 1/ Turn the wheels to modify the sound. You can specify the type of change that occurs (p. 15). 2 [L] switch Turns the power on/off. [VOLUME] knob Adjust the overall volume of the RD-88. [TONE COLOR] knob Varies the tonal character or sound image (p. 16). If the [EQ ADJUST] button is lit, this operates as the EQ [LOW] knob (p. 17). [MFX] knob Adjust the depth of the effect (p. 16). If the [EQ ADJUST] button is lit, this operates as the EQ [MID] knob (p. 17). [CHORUS/DELAY] knob Adjust the chorus/delay depth (p. 15). If the [EQ ADJUST] button is lit, this operates as the EQ [HIGH] knob (p. 17). [REVERB] knob Adjusts the reverb depth (p. 14). [EQ ADJUST] button Turn this on when you want to adjust the EQ. When this button is on (lit), you can use the above three knobs to adjust the EQ (p. 17). [ASSIGN] button You can assign desired parameters to the knobs for adjustment. When this button is on (lit), the knobs adjust the values of the assigned parameters (p. 20). [COMPRESSOR] button Turns the compressor on/off (p. 15). [TRANSPOSE] button Lets you transpose your performance (p. 14). LEVEL [LOWER], [UPPER2], [UPPER1] knobs Adjust the volume of each zone (p. 13). LEVEL [MIC/LINE IN] knob Adjusts the input level of MIC/LINE. [SPLIT] button Turns the Split Mode on/off (p. 11). This lets you divide the keyboard into left and right regions and play a different sound in each. By pressing this button and the [DUAL] button simultaneously, you can listen to demo songs (p. 10). [DUAL] button Turns the Dual Mode on/off (p. 11). This layers UPPER 1 and UPPER 2 tones together across the entire keyboard. By pressing this button and the [SPLIT] button simultaneously, you can listen to demo songs (p. 10). [EXTERNAL CTRL SETTING] button Accesses a screen where you can make settings for controlling an external MIDI sound module (p. 21).
Top Panel.
1 2 3 4 5
Panel Descriptions [MIC/LINE IN SETTING] button Accesses the MIC/LINE input setting screen. You can apply EQ and reverb to the MIC/LINE input (p. 7). 3 Display Shows the Scene names and the values of various settings, etc. 4 [<] [>] [ ] [ ] buttons Press these to switch pages and to move the cursor. [INC] [DEC] buttons Modify values. If you keep on holding down one button while pressing the other, the value change accelerates. [SHIFT] button You can easily call up Edit screens for related parameters by holding down this button while pressing buttons, turning knobs, or operating other controllers (refer to “List of Shortcut Keys” ). If you edit a parameter value while holding down this button, the value will change more greatly. [EXIT] button Press to return to a previous screen or to cancel a procedure that is in progress. [ENTER] button Press this to con rm a value or execute an operation. 5 [ONE TOUCH PIANO] button Recalls a piano sound (Scene). You can also make settings so that a favorite sound is recalled instead of a piano sound (p. 11). NOTE Note that when you press this button to recall a piano sound, the settings you’re editing are lost. FAVORITE [ON] button Turns on/off the function (FAVORITE function) that recalls favorite sounds you’ve registered (p. 18). FAVORITE [BANK] button Selects the bank of FAVORITE memories (p. 18) in which you can register your favorite sounds. [MENU] button The MENU screen appears. [WRITE] button The WRITE screen appears. [KEY TOUCH] button Accesses a screen where you can make keyboard touch settings (p. 13). SONG/RHYTHM [SELECT] button Accesses a screen where you can select songs or rhythms (p. 19, p. 20). SONG/RHYTHM [s] button Starts/stops playback of the song or rhythm (p. 19, p. 20). [SPEAKER ON] button Turns the internal speakers on/off. The internal speakers turn off when headphones are plugged into the headphone jack, but pressing this button turns on the speakers even if headphones are connected. You can also turn off the speakers even if headphones are not connected. [PANEL LOCK] button Long-press this button to turn panel lock on/off (a function that disables panel operations)(p. 17). [PIANO]–[OTHER] buttons / [0]–[9] buttons Select Tone (Scene) categories (p. 11). If the [FAVORITE] button or the [BANK] button are lit, these buttons operate as [0]–[9] buttons (p. 18).
List of Shortcut Keys
- “ [A]+[B] ” indicates the operation of “holding down the [A] button and pressing the [B] button.” Shortcut Explanation [SHIFT] + [DEC] [SHIFT] + [INC] Changes the value in steps of 10. When the Scene screen is shown, this changes the Scene category. [SHIFT] + Favorite [BANK], or [SHIFT] + Favorite [ON] Accesses the Favorite list. [SHIFT] + operate a knob 1–4 Jumps to the parameter edit screen for thecorresponding knob. [SHIFT] + operate a knob 1–
- If the [ASSIGN] button is on Jumps to the knob assignment edit screen. [SHIFT] + operate a WHEEL 1/2 Jumps to the wheel assignment screen. [SHIFT] + operate a pedal Jumps to the pedal assignment screen.
Panel Descriptions 7 MIDI OUT connector Transmits MIDI messages to an external MIDI device connected here. PEDAL jacks (DAMPER/R, FC2/C, FC1/L) Connecting the pedal switch provided with the RD-88 to the DAMPER jack allows you to use the switch as a damper pedal. With a pedal connected to the FC1 or FC2 jack, you can then assign a variety of functions to the pedal (p. 20).
- Use only the speci ed expression pedal. By connecting any other expression pedals, you risk causing malfunction and/or damage to the unit. 8 INPUT jacks (MIC, LINE) You can connect a mic or external audio device, and use the mic to sing while you perform, or perform along with a song that plays back from your external audio device Jack Explanation MIC Connect a mic (sold separately) to this jack. LINE This is an audio input jack. You can connect your audio player orother audio source here. MEMO 5 Use the [MIC/LINE IN] knob to adjust the volume. 5 The RD-88 supports dynamic mics. Condenser mics are not supported. 5 You can apply EQ and reverb to the input audio. Press the [MIC/ LINE IN SETTING] button to access the setting screen. You can also access the same screen via [MENU] 0 [INPUT SETTING]. For details on the parameters that can be set, refer to “Parameter Guide” (PDF). OUTPUT jacks (L/MONO, R) These are connected to an amp or other device. For mono output, use the L/MONO jack. PHONES jack You can connect a set of headphones here.
Overview of the RD-88
Basic Organization of the RD-88
RD-88 can be divided into two sections: a controller section and a sound generator section. Controller Section (controllers such as keyboard, modulation wheels, etc.) Sound Generator Section Play Controller Section This section includes the keyboard, the modulation wheels, the panel knobs, the sliders, and any pedal connected to the rear panel. Actions such as pressing and releasing of keys on the keyboard, depressing a damper pedal, and so forth, are converted to MIDI messages and sent to the sound generator section, or to an external MIDI device. Sound Generator Section The sound generator section produces the sound. Here, MIDI messages received from the controller section or external MIDI device are converted to musical signals, which are then output as analog signals from the OUTPUT and PHONES jacks.
About Scenes.
RD-88 lets you store the sounds that you create. A sound you create is called a “Scene”; you can use the buttons to recall a Scene and then play it. Scene Zone (UPPER 1) Zone (UPPER 2) Zone (UPPER 3) Rhythm Reverb Chorus Tone MFX EQ EQ EQ MFX MFX Tone Tone Tone Color Tone Color Tone Color Compressor Equalizer Resonance IFX/Sympathetic Zone The RD-88 features three parts (UPPER 1, UPPER 2, and LOWER) that you can use for freely controlling the internal parts with the RD-88’s buttons and keyboard. These three parts that are used for controlling the internal parts are collectively known as the “Zone.” Furthermore, you can freely control external MIDI sound generators with the RD-88 in the same manner as with the Zone. You can likewise control the external MIDI sound generator with the three parts (UPPER 1, UPPER 2, and LOWER), with this group of three parts being referred to as the “EXTERNAL Zone.” The external MIDI sound generator is assigned to these three parts for control. Tone The individual sounds used when playing the RD-88 are referred to as “Tones.” Tones are assigned to each zone. Rhythm Drum patterns for a variety of musical genres such as jazz and rock are built in. You can play back these patterns. Effects Each zone 1–3 provides a MFX, EQ, and Tone Color that can be set independently for each zone. There are also reverb, Chorus, and IFX/Sympathetic Resonance that can be used in common by all zones.
Performance
Listening to the Demo (DEMO PLAY)
Here’s how to listen to the demo songs.
NOTE
5 No data for the music that is played will be output from MIDI OUT
connectors.
5 The RD-88’s keyboard will not produce sound while the demo
songs are playing.
1
2
3
2
4 5
MEMO
When you enter demo mode, any unsaved settings are lost.
Store any arrangements of settings that you want to keep in Scene or
System (p. 23).
1. Hold down the [SPLIT] button and press the [DUAL]
button.
The RD-88 enters the demo mode. The Demo screen appears.
2. Use the Cursor [ ] [ ] buttons or the [DEC] [INC]
buttons to select a demo song.
3. Press the [ENTER] button to start playback of the
demo song.
4. Press the [EXIT] button to stop a demo song during
playback.
5. Press the [EXIT] button while the song is stopped to
nish with the Demo mode.
You will return to the previous screen.
Piano Performances
Now, try performing with the piano.
The RD-88 lets you call up the ideal settings for piano performance
at any time simply by pressing a button. You can also select your
preferred tones and settings and store them to the RD-88’s buttons.
2
1
1. Press the [PIANO] button or the [E. PIANO] button.
Pressing the [PIANO] button sets the entire keyboard to play with
the piano tone.
Pressing the [E. PIANO] button sets the entire keyboard to play
with the electric piano tone.
2. Use the [DEC] [INC] buttons to select a Scene.
MEMO
In the Scene screen, when the cursor is at the Scene number, you
can press the [ENTER] button to access a list of Scenes. You can use
the cursor buttons to select a Scene. After selecting a Scene, press
the [EXIT] or [ENTER] button to return to the Scene screen.
Making Detailed Settings
With the RD-88, you can also make more detailed settings
to make the sound even better match your favorite piano
performances. Con gurations can be stored for each Scene.
For details on the Scene parameter settings, refer to“Making
Detailed Settings for Tones” (p. 23).
NOTE
When you edit a setting, an “*” will appear.
If you turn off the power or select a One Touch tone or a Scene while
the “*” is shown, the changes you made will be discarded. If you want
to keep the settings, save the Scene (p. 23).
Performance Performing with a Variety of Scenes The RD-88 comes with a many built-in Sounds. Each one of these individual sounds is called a “Scene.” Scenes are assigned to the Scene category buttons according to the tone category selected. Each category has several Scenes. Try selecting and performing with a number of different Scenes. 1 2
- Press any of the Scene category buttons to select the category. The indicator of the selected Scene category button will light.
- Use the [DEC] [INC] buttons to select the Scene. Play the keyboard, and you will hear the selected Scene. NOTE If you turn off the power or select a different Scene when an “*” is shown in the display, the setting changes you’ve made will be discarded. If you want to keep the settings, save the Scene (p. 23). Playing Multiple Tones with the Keyboard The RD-88 features three Internal zones (UPPER 1, UPPER 2, and LOWER), and one tone can be assigned to each of these zones. You can perform using combinations of tones by turning each zone on or off. You can have multiple tones layered together at the same time, and even have different tones played in the left and right parts of the keyboard. UPPER 1 UPPER 2 LOWER
Performing with Layered Tones (Dual Mode)
This mode lets you play the UPPER 1 and UPPER 2 tones layered across the entire keyboard. 1 2
- Press the [DUAL] button, getting the indicators to light. Try ngering the keyboard. The Tones for UPPER 1 and UPPER 2 are layered and played. The screen shows the UPPER 2 tone.
- To nish the DUAL MODE, press the [DUAL] button once again, to make the indicator light goes out. The Tones for UPPER 1 played. MEMO You can also layer three tones by adding the LOWER tone. For details, refer to “Making Detailed Settings for Tones” (p. 23).
Performance
Adjusting the Volume Level for Individual Zones You can use the LEVEL [LOWER], [UPPER2], and [UPPER1] knobs to adjust the volume of each zone. MEMO Use the [VOLUME] knob when adjusting the overall volume level (p. 4). Changing the Key Touch You can make advanced settings for the touch used for the keys. 1 3 2
- Press the [KEY TOUCH] button. The keyboard touch settings screen appears.
- Use the cursor [ ] [ ] buttons to select a parameter, and use the [DEC] [INC] buttons to change its value.
- Press [EXIT] to return to the previous screen. MEMO The key touch settings can be saved individually for each Scene. To save the settings, refer to “Saving a Scene (Write)” (p. 23). Parameter Value Explanation Source SCENE The key touch settings speci ed by theScene are enabled. SYS The key touch settings speci ed for the system are enabled. MEMO If you want the key touch to be the same for multiple Scenes, set Source to “SYS.” You can access the shared key touch settings via [MENU] 0 [SYSTEM] 0 [KEY TOUCH]. To save the settings, execute the system write operation (p. 27). If you’ve selected a Scene whose Source is set to “SYS,” you can press the [KEY TOUCH] button to access the SYSTEM Key Touch setting screen. Velo Crv (Velocity Curve) SPR LIGHT An even lighter setting than LIGHT. LIGHT This sets the keyboard to a light touch. You can achieve fortissimo (ff ) play with a less forceful touch than usual, so the keyboard feels lighter. This setting makes it easy to play, even for children. MEDIUM This sets the keyboard to the standard touch. You can play with the most natural touch. This is the closest to the touch of an acoustic piano. HEAVY This sets the keyboard to a heavy touch. You have to nger the keyboard more forcefully than usual in order to play fortissimo (ff ), so the keyboard touch feels heavier. Dynamic ngering adds even more feeling to what you play. SPR HEAVY An even heavier setting than HEAVY. Velo Offset (Velocity Offset) -10–+ This setting provides even more precise adjustment of the key touch than available with the Velocity Curve setting alone. This allows you to achieve a more precise setting for the Velocity Curve by specifying an intermediate value between Key Touch settings. The touch sensitivity becomes heavier as the value increases. When this parameter is set to a value that exceeds the upper or lower limit, the setting for Velocity Curve (one of ve possible values) is automatically changed to accommodate the value you’ve speci ed. Velocity REAL Volume levels and the way sounds areplayed change in response to the velocity. 1– The xed velocity value you specify here will determine the volume and the way the sound is produced, regardless of your keyboard playing strength. Velo Dly Sens (Velocity Delay Sensitivity) -63–+ This sets the interval from the time the key is played to when the sound is produced. As the value is decreased, the timing of the sound is delayed more when more force is used to play the keys. As the value is increased, the timing of the sound is delayed more when less force is used to play the keys. Velo Keyfollow (Velocity Keyfollow Sensitivity) -63–+ This setting changes the touch sensitivity according to the key range being used. As the value is increased, the touch becomes heavier in the upper registers, and lighter in the lower keys. KeyOff Pos (Key Off Position) STANDARD Note-off will occur at the depth of aconventional piano. DEEP Note-off will occur at a deeper position is suitable for electric piano sounds.
Performance
Transposing the Key of the Keyboard (TRANSPOSE)
(TRANSPOSE) You can transpose performances without changing the keys you are playing. This feature is called “Transpose.” This is a convenient feature to use when you want to match the pitch of the keyboard performance to a vocalist’s pitch, or perform using the printed music for trumpets or other transposed instruments. You can adjust the transpose setting in semitone steps over a range of -5–0–+6 relative to C4. The Transpose has been set at the factory to “0.” 1 2 3
- Hold down the [TRANSPOSE] button for several seconds. The Transpose screen appears, and the current value of the setting is displayed.
- Hold down the [TRANSPOSE] button and press a key. If you press the C4 (middle C) key, the transpose amount will be set to “0.” For example, to have “E” sound when you play “C” on the keyboard, hold down the [TRANSPOSE] button and press the E key. The degree of transposition then becomes “+4.” When you release the [TRANSPOSE] button, the previous display will reappear. When the amount of transposition is set, the Transpose function switches on, and the [TRANSPOSE] button lights up. MEMO 5 You can also transpose by holding down the [TRANSPOSE] button and using the [DEC] [INC] buttons. 5 If you hold down the [TRANSPOSE] button and press F#4 or a higher key, the transpose amount is set to [+6]. 5 If you hold down the [TRANSPOSE] button and press G3 or a lower key, the transpose amount is set to [-5].
- To turn off Transpose, press the [TRANSPOSE] button so that its indicator goes off. The next time [TRANSPOSE] button is pressed, the sound is transposed by an amount corresponding to the value set here. NOTE 5 If the transpose amount is 0, the [TRANSPOSE] button will not turn on even if you press it. 5 When you turn the power off, the transpose amount returns to 0.
Adding Reverberation to the Sound (REVERB)
(REVERB) The RD-88 can apply a reverb effect to the notes you play on the keyboard. Applying reverb adds pleasing reverberation to what you play, so it sounds almost as if you were playing in a concert hall. 1
- Turn the [REVERB] knob. The depth of the reverb effect changes. You can adjust the reverb depth in a range of 0–127. MEMO You can select the type of reverb in the MENU screen 0 “SYSTEM EFFECTS” 0 “Sys Reverb” page. NOTE In the [MENU] 0 [SCENE EDIT] 0 [ZONE EDIT] 0 “INTERNAL” page, if the “Rev Send (reverb send)” value is set to “0,” no reverb effect is applied. Also, depending on the settings of the Scene, there might be cases in which turning the knob does not apply an effect. For details, refer to “Making Detailed Settings for Tones” (p. 23).
Performance
Adjusting the Character of the Sound (TONE COLOR).
(TONE COLOR) Turning the [TONE COLOR] knob will modify an aspect of the sound, such as its character or acoustic image. 1
- Turn the [TONE COLOR] knob. The effect assigned to the knob is applied. You can assign one or the other of the following effects to the [TONE COLOR] knob. Parameter Explanation Stereo Width If the sound is being output in stereo, turning the knob to the left gradually transforms the audio output to mono, and turning the knob to the right transforms it to stereo. Depending on your performing situation, the mono sound might be better for listening. EQ This lets you adjust the EQ using a single knob. Turning the knob to the left boosts the mid-frequency region, and turning the knob to the right boosts the high-frequency and low-frequency regions. Adjusting this appropriately for your performing situation might make the sound better for listening. MEMO The Tone Color assignment is speci ed in [MENU] 0 [SCENE EDIT] 0 [ZONE SOUND] 0 TONE COLOR. If you want to save the setting, save the Scene (p. 23).
Adding Breadth to the Sound (CHORUS/DELAY)
(MFX) In addition to chorus (p. 15) and reverb (p. 14), the RD-88 lets you apply a “multi-effect.” The multi-effect lets you choose from a variety of effect types including distortion and rotary. With the factory settings, an effect appropriate for each tone is assigned. 1
- Turn the [MFX] knob to adjust the effect. The multi-effect speci ed for the selected tone is applied. MEMO The effect is applied to the MFX of the currently selected zone. The value that changes when you turn the knob is pre-speci ed according to the type. For some effect types, it might be di cult to notice the effect. If the tone’s MFX setting is set to “Thru,” no effect is applied. MFX settings can also be speci ed for individual Scenes. For details, refer to “Parameter Guide” (PDF).
Performance
Adjusting the Levels of Each Frequency Range (EQUALIZER)
Range (EQUALIZER) The RD-88 is equipped with an equalizer. You can use the EQ [LOW] knob, [MID] knob, and [HIGH] knob to adjust the level of each frequency range. NOTE Equalization is applied to the overall sound output from the OUTPUT jacks.
- Press the [EQ ADJUST] button. 1 The button is lit, and the knob functions change as follows. 5 [TONE COLOR] knob 0 EQ [LOW] knob 5 [MFX] knob 0 EQ [MID] knob 5 [CHORUS/DELAY] knob 0 EQ [HIGH] knob
- Turn the knobs to adjust the levels in each range. Turning the EQUALIZER [LOW], [MID], or [HIGH] knobs toward the left will decrease the level of the corresponding range; turning the knobs toward the right will increase the level. MEMO In MENU 0 SYSTEM EFFECTS 0 Master EQ you can make detailed EQ settings. NOTE 5 Sounds may be distorted with certain knob settings. If this occurs, adjust the Input Gain on the “Master EQ” screen. 5 EQ settings are preserved even if you change Scenes, but are lost if you turn the power off. If you want to save the EQ settings, execute “Saving the System Effects (Write)” (p. 23).
Disabling the Buttons (Panel Lock)
The panel lock function allows you to temporarily disable the buttons so that their settings will not be accidentally changed, for example while you’re on stage. 1
- Long press the [PANEL LOCK] button. The panel will be locked, and the screen shown below will appear. When you once again long-press the [PANEL LOCK] button, panel lock is defeated. MEMO You can operate the knobs and wheels even when the panel is locked.
Using the Convenient Functions in Performances
Playing Rhythm.
The RD-88 features internal drum patterns complementing Jazz, Rock, and other various musical genres. These drum patterns are referred to as “Rhythms.” 1 2 3
- Press the [SELECT] button to make the button indicator light. The SONG/RHYTHM screen will appear.
- If the SONG screen appears, press the [SELECT] button once again to switch to the RHYTHM screen. Each time you press the [SELECT] button, you’ll alternate between the SONG screen and the RHYTHM screen.
- Press the [ ] button so it’s lit. The rhythm will begin sounding. When you press the [ ] button once again to turn off its light, the rhythm will stop. MEMO If you press the [SELECT] button to switch to the SONG screen while a rhythm is playing, the rhythm will stop.
Changing Rhythm Tempos
- In the RHYTHM screen, press the cursor button to move the cursor to the tempo indication in the top line of the screen.
- Use the [DEC] [INC] buttons to change the tempo. The Rhythm are played at the selected tempo.
Changing the Key Touch
You can select the way a Rhythm is played (the pattern) to match a variety of different musical genres.
- In the RHYTHM screen, use the cursor buttons to move the cursor to the rhythm number shown in the screen.
- Use the [DEC] [INC] buttons to change the patterns. The rhythm’s pattern will change.
- To stop the rhythm, press the [ ] button so its indicator is off.
Using the Convenient Functions in Performances
Playing Songs
You can copy an audio le (MP3 or WAV) from your computer to a USB ash drive, and perform on the RD-88 while that audio le plays back.
- Format your USB ash drive on the RD-88. “Formatting a USB Flash Drive (FORMAT USB MEMORY)” (p. 27) MEMO 5 Use a commercially available USB ash drive. However, we cannot guarantee operation with all commercially available ash drives. 5 We recommend that you use single-byte alphanumeric characters for the le name. If you use double-byte characters, the le name will not be shown correctly in the display.
- Copy the audio le into the “SONG LIST” folder. Audio les that can be played MP Format MPEG-1 audio layer 3 Sampling Frequency 48 kHz Bit rate 32/40/48/56/64/80/96/112/128/160/192/224/256/320 kbps, VBR (Variable Bit Rate) WAV Sampling Frequency 48 kHz Bit Depth 16/24-bit
- For both MP3 and WAV, the only sampling frequency supported is 48 kHz. If your le has a sampling frequency of other than 48 kHz, use software on your computer to convert it to 48 kHz beforehand.
- Connect the USB ash drive to the USB MEMORY port of the RD-88.
- Press the [SELECT] button to make the button indicator light. The SONG/RHYTHM screen will appear.
- Press the [SELECT] button to access the SONG screen. Each time you press the [SELECT] button, you’ll alternate between the SONG screen and the RHYTHM screen.
- Move the cursor to the song number and use the [DEC] [INC] buttons to select a song.
- To play the song, press the [ ] button to make it light. When you press the [ ] button to turn off its light, the song will stop playing. MEMO Move the cursor to “Volume” and use the [DEC] [INC] buttons to adjust the volume of the song. If you want to save the volume setting, execute the System Write operation (p. 27).
Assigning the Function of Each Controller
You can change the parameters that are controlled by the [1]–[8] knobs, WHEEL 1/2, and pedals FC1/FC2.
- Press the [MENU] button.
- Use the cursor [ ] [ ] buttons to select “SYSTEM,” and then press the [ENTER] button.
- Use the cursor [ ] [ ] buttons to select “ASSIGN” and then press the [ENTER] button.
- Use the cursor [<] [>] buttons to select the controller whose assignment you want to change.
- Use the cursor [ ] [ ] buttons to select a parameter, and use the [DEC] [INC] buttons to change its value. For details, refer to “Parameter Guide” (PDF).
- If you want to save the setting, execute the System Write operation. “Saving the System Settings (System Write)” (p. 27) MEMO The settings of these controllers can be speci ed and remembered individually for each Scene. This is convenient when you want to switch the controller assignments for each sound (Scene). In the Scene edit parameters, change each controller’s Source from System to Scene. For details, refer to “Parameter Guide” (PDF).
Using the [ONE TOUCH PIANO] Button
With the factory settings, pressing the [ONE TOUCH PIANO] button recalls the piano sound of Scene 001. Alternatively, you can assign a favorite Scene to the [ONE TOUCH PIANO] button by using the following procedure. The Scene assigned to the [ONE TOUCH PIANO] button is the Scene that is rst selected at start-up.
- Select a favorite Scene.
- Hold down the [WRITE] button and press the [ONE TOUCH PIANO] button. The current settings are saved to the [ONE TOUCH PIANO] button.
